IP66 Waterproof SMD LED Street Lights 50W-200W for Outdoor Garden and Road Lighting

The HS-HC04 street light features a durable die-cast aluminum body and polycarbonate lens for effective heat dissipation. Built for long-term reliability, it meets safety standards and includes a photocell sensor for automatic dusk-to-dawn operation, ensuring energy efficiency.

Model:
HS-HC04
Category:
Mains
Application:
Outdoor
Material:
Die-cast Aluminum+PC
Colour:
Gray
Induction:
Photocell Sensor
CCT Turnable:
No-Single CCT
Control Method:
No Control Function
Stock Status:
In Stock
Protection Level:
IP66
Certification:
CE / RoHS / IEC 60598-1 / IP Rating Test Report

Inquire Now

Product Details

SMD 2835 High Brightness Chips: High luminous output, low heat, and excellent color rendering for efficient lighting.

PC Optical Lens: Impact-resistant lens with clarity, UV protection, and high optical performance.

Die-cast Aluminium Housing: Corrosion-resistant housing for heat dissipation and outdoor protection.

Mounting Bracket: Sturdy die-cast aluminum bracket with 90° adjustable angle for secure installation.

ANSI C136.10 Photocell Sensor: Dusk-to-dawn control with weather-resistant housing, compatible with top/side mounting and retrofit options.

Model No.	HS-HC04-50W	HS-HC04-100W	HS-HC04-150W	HS-HC04-200W
Nominal Wattage	50W	100W	150W	200W
Nominal Volts	100-265 VAC
Light Bead	3030 SMD/72PCS	3030 SMD/144PCS	3030 SMD/216CS	3030 SMD/288PCS
Luminance Efficiency	120Lm/W
Luminous Flux	6000Lm	12000Lm	18000Lm	24000Lm
Beam Angle	75°*140°
CRI	80+
Materials	Die-cast aluminium Housing + PC lens
IP	Rating IP66
Size（mm）	11571448	13071499	16571569	19971684
